A deeper shade of green: inspiring sustainable drug manufacturing

 drugs  Comments Off on A deeper shade of green: inspiring sustainable drug manufacturing
Jan 062017


Graphical abstract: A deeper shade of green: inspiring sustainable drug manufacturing

Green and sustainable drug manufacturing go hand in hand with forward-looking visions seeking to balance the long-term sustainability of business, society, and the environment. However, a lack of harmonization among available metrics has inhibited opportunities for green chemistry in industry. Moreover, inconsistent starting points for analysis and neglected complexities for diverse manufacturing processes have made developing objective goals a challenge. Herein we put forward a practical strategy to overcome these barriers using data from in-depth analysis of 46 drug manufacturing processes from nine large pharmaceutical firms, and propose the Green Aspiration Level as metric of choice to enable the critically needed consistency in smart green manufacturing goals. In addition, we quantify the importance of green chemistry in the often overlooked, yet enormously impactful, outsourced portion of the supply chain, and introduce the Green Scorecard as a value added sustainability communication tool.

http://pubs.rsc.org/en/Content/ArticleLanding/2017/GC/C6GC02901A?utm_medium=email&utm_campaign=pub-GC-vol-19-issue-1&utm_source=toc-alert#!divAbstract

The Green Aspiration Level (GAL) has been constructed on four pillars to ensure consistent application, namely (1) clearly defined synthesis starting points,1 (2) unambiguous complete E factor (cEF)2,3 or Process Mass Intensity (PMI) waste metrics, (3) historical averages of industrial drug manufacturing waste, and (4) complexity of the drug’s ideal manufacturing process (Supplementary Figure 6). cEF or PMI can be used interchangeably in GAL-based analysis enabling organizations using either to calculate their green performance scores. cEF and PMI differ by just one unit (Supplementary Equation 6) and share the same commercial waste goal for an average manufacturing step4 – the transformation-GAL or tGAL – that results in negligible numerical differences from the inclusion of one or the other. The pharmaceutical industry has generally adopted PMI. However, our publication utilizes cEF values due to literature prevalence and potentially broader appeal of E factors.5 It is important to note that all reaction and workup materials are included in the analysis, but excluded are reactor cleaning6 and solvent recycling.7 Standardized process starting points are a critical component of the GAL methodology. A starting material for some may be an intermediate for others. Until recently, the scientific community lacked an unambiguous definition of process starting points in the assessment of process greenness. This has been a bothersome source of inconsistency. Failure to define an appropriate starting material can lead to exclusion of significant amounts of intrinsic raw material waste created during earlier stages of manufacture. We therefore utilize these updated definitions of process analysis starting points to ensuring higher quality of data:8

1) The material is commercially available from a major reputable chemical laboratory catalog company, and its price is listed in the (online) catalog. Materials requiring bulk or custom quotes do not qualify as process starting material. AND 2) The laboratory catalog cost of the material at its largest offered quantity does not exceed US $100/mol. Therefore, published literature must be researched if the material does not qualify as process starting material in order to determine its correct intrinsic cEF. However, we realized that determination of literature cEF values is tedious and involves making assumptions since literature procedures are often incomplete compared to internal or external manufacturing batch records. Thus, standardizing Literature cEF quickly became a desirable goal. In order to facilitate literature analysis we introduced Supplementary Equation 7 that just requires determination of literature step count from ≤$100/mol starting materials without having to retrieve literature waste information.9 The literature step multiplier of 37 kg/kg represents the average literature step cEF across the analyzed projects (Supplementary Table 1), so it equals their average literature cEF (76 kg/kg) divided by average literature step count (2.1). The process cEF and Relative Process Greenness (RPG) derived from the simplified calculated cEF literature values are shown next to their progenitors in Supplementary Table 3. We observe that average calculated and manually determined cEF and RPG values are comparable and within 10% of their means across the three development phases. Thus, we consider the simplified method sound and an importtant element to achieving consistency in green process analysis.



str1 str2 str3 str4

A deeper shade of green: inspiring sustainable drug manufacturing

 *Corresponding authors
aChemical Development, Boehringer Ingelheim Pharmaceuticals, Ridgefield, USA
E-mail: frank.roschangar@boehringer-ingelheim.com
bPharmaceutical Sciences – Worldwide Research & Development, Pfizer, Groton, USA
cPfizer, Sandwich, UK
dChemical & Analytical Development, Novartis Pharma, 4002 Basel, Switzerland
eAPI Chemistry, GlaxoSmithKline Medicines Research Centre, Stevenage, UK
fSmall Molecule Process Chemistry, Genentech, a Member of the Roche Group, South San Francisco, USA
gSmall Molecule Design and Development, Eli Lilly and Company, Indianapolis, USA
hChemical and Synthetic Development, Bristol-Myers Squibb, New Brunswick, USA
iProcess Chemistry, Merck, Rahway, New Jersey 07065, USA
jProcess Development, Amgen, Thousand Oaks, USA
kMolecular Sciences Institute, School of Chemistry, University of the Witwatersrand, Johannesburg, South Africa
lDelft University of Technology, 2628 BL Delft, Netherlands
Green Chem., 2017,19, 281-285

DOI: 10.1039/C6GC02901A

Frank Roschangar, PhD MBA

Frank Roschangar, PhD MBA

Pharmaceutical process research director, passionate about accelerating drug development and driving green chemistry.

Boehringer Ingelheim
Ingelheim am Rhein, Germany

Research experience

  • Feb 2002–Sep 2015
     Director
    Boehringer Ingelheim
    Germany · Nieder-Ingelheim
  • Aug 1996–Feb 1998
    Postdoc
    The Scripps Research Institute · Skaggs Institute for Chemical Biology · Prof. K.C. Nicolaou
    United States · La Jolla
  • Aug 1992–Aug 1996
    PhD Candidate
    Rice University · Department of Chemistry
    United States · Houston
Supplementary References
1. The $100 per mol laboratory catalog pricing requirement described in Supplementary Discussion 1 does not apply to reagents, catalysts, ligands, and solvents, since they are produced for widespread application and are not specific to the process being evaluated.
2. Since the original E factor has been applied inconsistently, the cEF metric was introduced for the purpose of GAL analysis. cEF accounts for all process reaction and process workup materials, including raw materials, intermediates, reagents, process aids, solvents, and water.
3. All E factors reported herein represent the cEF or sEF contributions of the overall manufacturing process or the sub-process (e.g. external cEF, literature cEF) to produce 1 kg of drug substance.
4. We define a step as a chemical operation involving one or more chemical transformations that form and/or break covalent or ionic bonds and lead to a stable and isolable intermediate, but not necessarily include its isolation. Examples: • Simultaneous removal of two or more protection groups involves multiple transformations, yet it is carried out in one chemical operation  counted as one step • Sequential transformations via a stable and isolable intermediate that are carried out in two operations but without intermediate workup  counted as two steps • Formation of covalent bonds or salts that occur during workup  not counted as an extra step • Separate operation of salt formation from an isolated intermediate  counted as one step • Isolation of a product, following work-up, as a solution that can be stored  counted as one step.
5. A SciFinder search for the terms ‘Process Mass Intensity’, and ‘E factor’ and ‘Environmental impact factor’ on Nov. 14, 2016 revealed that the PMI concept was present in 12, 8, 9, and 12 publications for the years 2013-2016, respectively, while the E factor concept was mentioned 39, 45, 57, and 46 times (76-86%), respectively.
6. The GAL considers only direct process materials, i.e. materials used in the chemical steps and their workups. It does not include solvents and aqueous detergents required for reactor and equipment cleaning between batches or steps, nor the frequency and duration of the equipment and facility specific cleaning operations. These parameters are considered for comprehensive environmental impact in Life Cycle Assessment (LCA) analysis.
7. In US pharmaceutical manufacturing, recycling accounts for 25% of waste handling, while energy recovery burning and treatment constitute 38% and 35%, based on 2012 data from ‘The Right-To-Know Network’ (RTKNET.ORG), Toxic Releases (TRI) Database: http://rtknet.org/db/tri.
8. The $100 per mol commodity pricing criterion was established in ref. 15 of the main article based on the author’s professional experience. The authors of this manuscript consider this figure appropriate and helpful for providing a consistent analysis.
9. If a detailed procedure is available for a particular literature step, its calculated waste can be used in place of the 37 kg/kg default value.
10. J. Li and M. D. Eastgate, Current Complexity: a Tool for Assessing the Complexity of Organic Molecules. Org. Biomol. Chem. 2015,13, 7164–7176.
11. D. P. Kjell, I. A. Watson, C. N. Wolfe and J. T. Spitler, Complexity-Based Metric for Process Mass Intensity in the Pharmaceutical Industry. Org. Process Res. Dev. 2013, 17, 169– 174.
12. R. P. Sheridan, et al., Modeling a Crowdsourcing Definition of Molecular Complexity. J. Chem. Inf. Model. 2014, 54, 1604–1616.
13. M. F. Faul, et al., Part 2: Designation and Justification of API Starting Materials: Current Practices across Member Companies of the IQ Consortium. Org. Process Res. Dev. 2014, 18, 594–600.
14. Besides offering simplicity, the GAL’s process complexity model was selected vs. the alternative structural complexity measures due to its inherent ideality-derived consideration for available synthetic methodology.
15. See main article ref. 16: it defines Construction Reactions (CR) as chemical transformations that form skeletal C-C or C-heteroatom bonds. Strategic Redox Reactions (SRR) are construction reactions that directly establish the correct functionality found in the final product, and include asymmetric reductions or oxidations. All other types of non-strategic reactions are considered as Concession Steps (CS), and include functional group interconversions, non-strategic redox reactions, and protecting group manipulations.
16. M. E. Kopach, et al., Process Development and Pilot-Plant Synthesis of (2-Chlorophenyl)[2-(phenylsulfonyl)pyridin-3- yl]methanone. Org. Process Res. Dev. 2010, 14, 1229–1238.
17. M. E. Kopach, M. M. Murray, T. M. Braden, M. E. Kobierski, O. L. Williams, Improved Synthesis of 1-(Azidomethyl)-3,5-bis- (trifluoromethyl)benzene: Development of Batch and Microflow Azide Processes. Org. Process Res. Dev. 2009, 13, 152–160. 18. RCI (Process B) = 1 − ( ) = 0.25. RCI (Process C) = 1 − ( ) = 0.38

//////////green chemistry, drugs

Share

Biocatalysis : Biological solutions to a growing world, Pregabalin case study

 drugs  Comments Off on Biocatalysis : Biological solutions to a growing world, Pregabalin case study
Oct 022016


str1



Biocatalysis : Biological solutions to a growing world
– Mr. Michael Foldager, Global Marketing Manager – Biocatalysis, Novozymes A/S, Denmark

Michael Foldager

Michael Foldager

Global Marketing Manager
Novozymes, Copenhagen · Business Development

Copenhagen, Denmark

December 4th, 2015 at “IGCW 2015” in Mumbai. India
 Image result for Novozymes

View presentation

Image result for waitThe presentation will load below


Image result for Novozymes



Image result for Novozymes



Image result for NovozymesAmerikansk lovgivning holder hånden under Novozymes, når der tales om majsbaseret bioethanol, da det er lovfæstet, at 10 pct. af brændstofforbruget skal kommer fra biobrændstof

novozymes_albumedix

albumedix_albumin_novozmes_synbio_denmark_nottingham_subsidiary_veltis

Animal-free yeast production of Albumin offers huge therapeutic potential in medicine (Source: Albumedix)



///////////Biocatalysis, Biological solutions,  growing world, Pregabalin,  case study, Michael Foldager, Global Marketing Manager, Novozymes, Copenhagen

Share

Dr Anthony’s New Drug Approvals hits 13 lakh views in 212 countries

 drugs  Comments Off on Dr Anthony’s New Drug Approvals hits 13 lakh views in 212 countries
Jun 082016


str1

Dr Anthony’s New Drug Approvals hits 13 lakh views in 212 countries

An Indian helping millions

9e3e7-new-india-map

MAKING INDIANS FEEL PROUD

LINK

https://newdrugapprovals.org/

////////blog, Dr Anthony , New Drug Approvals,  13 lakh views, 212 countries, India

Share

Printing with Collagen

 drugs  Comments Off on Printing with Collagen
May 132016


thumbnail image: Printing with Collagen

Printing with Collagen

Addition of collagen to hydrogels in 3D printing improves stem cell differentiation in osteogenesis

Read more

http://www.chemistryviews.org/details/news/9268521/Printing_with_Collagen.html



MORE ON

Collagen

Tropocollagen molecule: three left-handed procollagens (red, green, blue) join to form a right handed triple helical tropocollagen.

Collagen is the most common protein found in mammals.

Collagen /ˈkɒlən/ is the main structural protein in the extracellular space in the various connective tissues in animal bodies. As the main component of connective tissue, it is the most abundant protein in mammals,[1] making up from 25% to 35% of the whole-body protein content. Depending upon the degree of mineralization, collagen tissues may be rigid (bone), compliant (tendon), or have a gradient from rigid to compliant (cartilage).[2] Collagen, in the form of elongated fibrils, is mostly found in fibrous tissues such as tendons, ligaments and skin. It is also abundant incorneas, cartilage, bones, blood vessels, the gut, intervertebral discs and the dentin in teeth.[3] In muscle tissue, it serves as a major component of the endomysium. Collagen constitutes one to two percent of muscle tissue, and accounts for 6% of the weight of strong, tendinous muscles.[4] Thefibroblast is the most common cell that creates collagen.

Gelatin, which is used in food and industry, is collagen that has been irreversibly hydrolyzed.[5] Collagen also has many medical uses in treating complications of the bones and skin.

The name collagen comes from the Greek κόλλα (kólla), meaning “glue“, and suffix -γέν, -gen, denoting “producing”.[6][7] This refers to the compound’s early use in the process of boiling the skin and sinews of horses and other animals to obtain glue.





woman receiving injection to forehead
Collagen injections can be used in cosmetic procedures to improve the contours of aging skin.

Types of collagen

Collagen occurs in many places throughout the body. Over 90% of the collagen in the human body, however, is type I.[8]

So far, 28 types of collagen have been identified and described. They can be divided into several groups according to the structure they form:[2]

  • Fibrillar (Type I, II, III, V, XI)
  • Non-fibrillar
    • FACIT (Fibril Associated Collagens with Interrupted Triple Helices) (Type IX, XII, XIV, XVI, XIX)
    • Short chain (Type VIII, X)
    • Basement membrane (Type IV)
    • Multiplexin (Multiple Triple Helix domains with Interruptions) (Type XV, XVIII)
    • MACIT (Membrane Associated Collagens with Interrupted Triple Helices) (Type XIII, XVII)
    • Other (Type VI, VII)

The five most common types are:

  • Type I: skin, tendon, vascular ligature, organs, bone (main component of the organic part of bone)
  • Type II: cartilage (main collagenous component of cartilage)
  • Type III: reticulate (main component of reticular fibers), commonly found alongside type I.
  • Type IV: forms basal lamina, the epithelium-secreted layer of the basement membrane.
  • Type V: cell surfaces, hair and placenta

wrinkled mouth with cigarette
Tobacco contains chemicals that damage collagen

Medical uses

Cardiac applications

The collagenous cardiac skeleton which includes the four heart valve rings, is histologically and uniquely bound to cardiac muscle. The cardiac skeleton also includes the separating septa of the heart chambers – the interventricular septum and the atrioventricular septum. Collagen contribution to the measure of cardiac performance summarily represents a continuous torsional force opposed to the fluid mechanics of blood pressure emitted from the heart. The collagenous structure that divides the upper chambers of the heart from the lower chambers is an impermeable membrane that excludes both blood and electrical impulses through typical physiological means. With support from collagen, atrial fibrillation should never deteriorate to ventricular fibrillation. Collagen is layered in variable densities with cardiac muscle mass. The mass, distribution, age and density of collagen all contribute to the compliance required to move blood back and forth. Individual cardiac valvular leaflets are folded into shape by specialized collagen under variable pressure. Gradual calcium deposition within collagen occurs as a natural function of aging. Calcified points within collagen matrices show contrast in a moving display of blood and muscle, enabling methods of cardiac imaging technology to arrive at ratios essentially stating blood in (cardiac input) and blood out (cardiac output). Pathology of the collagen underpinning of the heart is understood within the category of connective tissue disease.

Hydrolyzed type II collagen and osteoarthritis

A published study[9] reports that ingestion of a novel low molecular weight hydrolyzed chicken sternal cartilage extract, containing a matrix of hydrolyzed type II collagen,chondroitin sulfate, and hyaluronic acid, relieves joint discomfort associated with osteoarthritis. A randomized controlled trial (RCT) enrolling 80 subjects demonstrated that it was well tolerated with no serious adverse event and led to a significant improvement in joint mobility compared to the placebo group on days 35 (p = 0.007) and 70 (p < 0.001).



Fast facts on collagen

Here are some key points about collagen. More detail and supporting information is in the main article.25-27

  • Protein makes up around 20% of the body’s mass, and collagen makes up around 30% of the protein in the human body.
  • There are at least 16 types of collagen, but 80-90% of the collagen in the body consists of types I, II, and III.
  • Type I collagen fibrils are stronger than steel (gram for gram).
  • Collagen is most commonly found within the body in the skin, bones and connective tissues.
  • The word “collagen” is derived from the Greek “kolla,” meaning glue.
  • Collagen gives the skin its strength and structure, and also plays a role in the replacement of dead skin cells.
  • Collagen production declines with age (as part of intrinsic aging), and is reduced by exposure to ultraviolet light and other environmental factors (extrinsic aging).
  • Collagen in medical products can be derived from human, bovine, porcine and ovine sources.
  • Collagen dressings attract new skin cells to wound sites.
  • Cosmetic products such as revitalizing lotions that claim to increase collagen levels are unlikely to do so, as collagen molecules are too large to be absorbed through the skin.
  • Collagen production can be stimulated through the use of laser therapy and the use of all-trans retinoic acid (a form ofvitamin A).
  • Controllable factors that damage the production of collagen include sunlight, smoking and high sugar consumption.

Cosmetic surgery

Collagen has been widely used in cosmetic surgery, as a healing aid for burn patients for reconstruction of bone and a wide variety of dental, orthopedic, and surgical purposes. Both human and bovine collagen is widely used as dermal fillers for treatment of wrinkles and skin aging.[10] Some points of interest are:

  1. When used cosmetically, there is a chance of allergic reactions causing prolonged redness; however, this can be virtually eliminated by simple and inconspicuous patch testing prior to cosmetic use.
  2. Most medical collagen is derived from young beef cattle (bovine) from certified BSE-free animals. Most manufacturers use donor animals from either “closed herds”, or from countries which have never had a reported case of BSE such as Australia, Brazil, and New Zealand.

Bone grafts

As the skeleton forms the structure of the body, it is vital that it maintains its strength, even after breaks and injuries. Collagen is used in bone grafting as it has a triple helical structure, making it a very strong molecule. It is ideal for use in bones, as it does not compromise the structural integrity of the skeleton. The triple helical structure of collagen prevents it from being broken down by enzymes, it enables adhesiveness of cells and it is important for the proper assembly of the extracellular matrix.[11]

Tissue regeneration

Collagen scaffolds are used in tissue regeneration, whether in sponges, thin sheets, or gels. Collagen has the correct properties for tissue regeneration such as pore structure, permeability, hydrophilicity and it is stable in vivo. Collagen scaffolds are also ideal for the deposition of cells, such as osteoblasts and fibroblasts and once inserted, growth is able to continue as normal in the tissue.[12]

Reconstructive surgical uses

Collagens are widely employed in the construction of the artificial skin substitutes used in the management of severe burns. These collagens may be derived from bovine, equine, porcine, or even human sources; and are sometimes used in combination with silicones, glycosaminoglycans, fibroblasts, growth factors and other substances.

Collagen is also sold commercially in pill form as a supplement to aid joint mobility. However, because proteins are broken down into amino acids before absorption, there is no reason for orally ingested collagen to affect connective tissue in the body, except through the effect of individual amino acid supplementation.

Collagen is also frequently used in scientific research applications for cell culture, studying cell behavior and cellular interactions with the extracellular environment.[13]

Wound care

Collagen is one of the body’s key natural resources and a component of skin tissue that can benefit all stages of the wound healing process.[14] When collagen is made available to the wound bed, closure can occur. Wound deterioration, followed sometimes by procedures such as amputation, can thus be avoided.

Collagen is a natural product, therefore it is used as a natural wound dressing and has properties that artificial wound dressings do not have. It is resistant against bacteria, which is of vital importance in a wound dressing. It helps to keep the wound sterile, because of its natural ability to fight infection. When collagen is used as a burn dressing, healthygranulation tissue is able to form very quickly over the burn, helping it to heal rapidly.[15]

Throughout the 4 phases of wound healing, collagen performs the following functions in wound healing:

  • Guiding function: Collagen fibers serve to guide fibroblasts. Fibroblasts migrate along a connective tissue matrix.
  • Chemotactic properties: The large surface area available on collagen fibers can attract fibrogenic cells which help in healing.
  • Nucleation: Collagen, in the presence of certain neutral salt molecules can act as a nucleating agent causing formation of fibrillar structures. A collagen wound dressing might serve as a guide for orienting new collagen deposition and capillary growth.
  • Hemostatic properties: Blood platelets interact with the collagen to make a hemostatic plug.

Chemistry

The collagen protein is composed of a triple helix, which generally consists of two identical chains (α1) and an additional chain that differs slightly in its chemical composition (α2).[16] The amino acid composition of collagen is atypical for proteins, particularly with respect to its high hydroxyproline content. The most common motifs in the amino acid sequence of collagen are glycineproline-X and glycine-X-hydroxyproline, where X is any amino acid other than glycine, proline or hydroxyproline. The average amino acid composition for fish and mammal skin is given.[16]

Amino acid Abundance in mammal skin
(residues/1000)
Abundance in fish skin
(residues/1000)
Glycine 329 339
Proline 126 108
Alanine 109 114
Hydroxyproline 95 67
Glutamic acid 74 76
Arginine 49 52
Aspartic acid 47 47
Serine 36 46
Lysine 29 26
Leucine 24 23
Valine 22 21
Threonine 19 26
Phenylalanine 13 14
Isoleucine 11 11
Hydroxylysine 6 8
Methionine 6 13
Histidine 5 7
Tyrosine 3 3
Cysteine 1 1
Tryptophan 0 0

Synthesis

First, a three-dimensional stranded structure is assembled, with the amino acids glycine and proline as its principal components. This is not yet collagen but its precursor, procollagen. Procollagen is then modified by the addition of hydroxyl groups to the amino acids proline and lysine. This step is important for later glycosylation and the formation of the triple helix structure of collagen. The hydroxylase enzymes that perform these reactions require Vitamin C as a cofactor, and a deficiency in this vitamin results in impaired collagen synthesis and the resulting disease scurvy[17] These hydroxylation reactions are catalyzed by two different enzymes: prolyl-4-hydroxylase[18] and lysyl-hydroxylase. Vitamin C also serves with them in inducing these reactions. In this service, one molecule of vitamin C is destroyed for each H replaced by OH. [19] The synthesis of collagen occurs inside and outside of the cell. The formation of collagen which results in fibrillary collagen (most common form) is discussed here. Meshwork collagen, which is often involved in the formation of filtration systems, is the other form of collagen. All types of collagens are triple helices, and the differences lie in the make-up of the alpha peptides created in step 2.

  1. Transcription of mRNA: About 34 genes are associated with collagen formation, each coding for a specific mRNA sequence, and typically have the “COL” prefix. The beginning of collagen synthesis begins with turning on genes which are associated with the formation of a particular alpha peptide (typically alpha 1, 2 or 3).
  2. Pre-pro-peptide formation: Once the final mRNA exits from the cell nucleus and enters into the cytoplasm, it links with the ribosomal subunits and the process of translation occurs. The early/first part of the new peptide is known as the signal sequence. The signal sequence on the N-terminal of the peptide is recognized by a signal recognition particle on the endoplasmic reticulum, which will be responsible for directing the pre-pro-peptide into the endoplasmic reticulum. Therefore, once the synthesis of new peptide is finished, it goes directly into the endoplasmic reticulum for post-translational processing. It is now known as pre-pro-collagen.
  3. Pre-pro-peptide to pro-collagen: Three modifications of the pre-pro-peptide occur leading to the formation of the alpha peptide:
    1. The signal peptide on the N-terminal is dissolved, and the molecule is now known as propeptide (not procollagen).
    2. Hydroxylation of lysines and prolines on propeptide by the enzymes ‘prolyl hydroxylase’ and ‘lysyl hydroxylase’ (to produce hydroxyproline and hydroxylysine) occurs to aid cross-linking of the alpha peptides. This enzymatic step requires vitamin C as a cofactor. In scurvy, the lack of hydroxylation of prolines and lysines causes a looser triple helix (which is formed by three alpha peptides).
    3. Glycosylation occurs by adding either glucose or galactose monomers onto the hydroxyl groups that were placed onto lysines, but not on prolines.
    4. Once these modifications have taken place, three of the hydroxylated and glycosylated propeptides twist into a triple helix forming procollagen. Procollagen still has unwound ends, which will be later trimmed. At this point, the procollagen is packaged into a transfer vesicle destined for the Golgi apparatus.
  4. Golgi apparatus modification: In the Golgi apparatus, the procollagen goes through one last post-translational modification before being secreted out of the cell. In this step, oligosaccharides (not monosaccharides as in step 3) are added, and then the procollagen is packaged into a secretory vesicle destined for the extracellular space.
  5. Formation of tropocollagen: Once outside the cell, membrane bound enzymes known as ‘collagen peptidases’, remove the “loose ends” of the procollagen molecule. What is left is known as tropocollagen. Defects in this step produce one of the many collagenopathies known as Ehlers-Danlos syndrome. This step is absent when synthesizing type III, a type of fibrilar collagen.
  6. Formation of the collagen fibril: ‘Lysyl oxidase’, an extracellular enzyme, produces the final step in the collagen synthesis pathway. This enzyme acts on lysines and hydroxylysines producing aldehyde groups, which will eventually undergo covalent bonding between tropocollagen molecules. This polymer of tropocollogen is known as a collagen fibril.

Action of lysyl oxidase

Amino acids

Collagen has an unusual amino acid composition and sequence:

  • Glycine is found at almost every third residue.
  • Proline makes up about 17% of collagen.
  • Collagen contains two uncommon derivative amino acids not directly inserted during translation. These amino acids are found at specific locations relative to glycine and are modified post-translationally by different enzymes, both of which require vitamin C as acofactor.

Cortisol stimulates degradation of (skin) collagen into amino acids.[20]

Collagen I formation

Most collagen forms in a similar manner, but the following process is typical for type I:

  1. Inside the cell
    1. Two types of alpha chains are formed during translation on ribosomes along the rough endoplasmic reticulum (RER): alpha-1 and alpha-2 chains. These peptide chains (known as preprocollagen) have registration peptides on each end and a signal peptide.
    2. Polypeptide chains are released into the lumen of the RER.
    3. Signal peptides are cleaved inside the RER and the chains are now known as pro-alpha chains.
    4. Hydroxylation of lysine and proline amino acids occurs inside the lumen. This process is dependent on ascorbic acid (vitamin C) as a cofactor.
    5. Glycosylation of specific hydroxylysine residues occurs.
    6. Triple alpha helical structure is formed inside the endoplasmic reticulum from two alpha-1 chains and one alpha-2 chain.
    7. Procollagen is shipped to the Golgi apparatus, where it is packaged and secreted by exocytosis.
  2. Outside the cell
    1. Registration peptides are cleaved and tropocollagen is formed by procollagen peptidase.
    2. Multiple tropocollagen molecules form collagen fibrils, via covalent cross-linking (aldol reaction) by lysyl oxidase which links hydroxylysine and lysine residues. Multiple collagen fibrils form into collagen fibers.
    3. Collagen may be attached to cell membranes via several types of protein, including fibronectin and integrin.

Synthetic pathogenesis

Vitamin C deficiency causes scurvy, a serious and painful disease in which defective collagen prevents the formation of strong connective tissue. Gums deteriorate and bleed, with loss of teeth; skin discolors, and wounds do not heal. Prior to the 18th century, this condition was notorious among long-duration military, particularly naval, expeditions during which participants were deprived of foods containing vitamin C.

An autoimmune disease such as lupus erythematosus or rheumatoid arthritis[21] may attack healthy collagen fibers.

Many bacteria and viruses secrete virulence factors, such as the enzyme collagenase, which destroys collagen or interferes with its production.

Molecular structure

A single collagen molecule, tropocollagen, is used to make up larger collagen aggregates, such as fibrils. It is approximately 300 nm long and 1.5 nm in diameter, and it is made up of three polypeptide strands (called alpha peptides, see step 2), each of which has the conformation of a left-handed helix – this should not be confused with the right-handedalpha helix. These three left-handed helices are twisted together into a right-handed triple helix or “super helix”, a cooperative quaternary structure stabilized by many hydrogen bonds. With type I collagen and possibly all fibrillar collagens, if not all collagens, each triple-helix associates into a right-handed super-super-coil referred to as the collagen microfibril. Each microfibril is interdigitated with its neighboring microfibrils to a degree that might suggest they are individually unstable, although within collagen fibrils, they are so well ordered as to be crystalline.

Three polypeptides coil to form tropocollagen. Many tropocollagens then bind together to form a fibril, and many of these then form a fibre.

A distinctive feature of collagen is the regular arrangement ofamino acids in each of the three chains of these collagen subunits. The sequence often follows the pattern GlyPro-X or Gly-X-Hyp, where X may be any of various other amino acid residues.[16] Proline or hydroxyproline constitute about 1/6 of the total sequence. With glycine accounting for the 1/3 of the sequence, this means approximately half of the collagen sequence is not glycine, proline or hydroxyproline, a fact often missed due to the distraction of the unusual GX1X2 character of collagen alpha-peptides. The high glycine content of collagen is important with respect to stabilization of the collagen helix as this allows the very close association of the collagen fibers within the molecule, facilitating hydrogen bonding and the formation of intermolecular cross-links.[16]This kind of regular repetition and high glycine content is found in only a few other fibrous proteins, such as silk fibroin.

Collagen is not only a structural protein. Due to its key role in the determination of cell phenotype, cell adhesion, tissue regulation and infrastructure, many sections of its non-proline-rich regions have cell or matrix association / regulation roles. The relatively high content of proline and hydroxyproline rings, with their geometrically constrained carboxyl and (secondary) amino groups, along with the rich abundance of glycine, accounts for the tendency of the individual polypeptide strands to form left-handed helices spontaneously, without any intrachain hydrogen bonding.

Because glycine is the smallest amino acid with no side chain, it plays a unique role in fibrous structural proteins. In collagen, Gly is required at every third position because the assembly of the triple helix puts this residue at the interior (axis) of the helix, where there is no space for a larger side group than glycine’s single hydrogen atom. For the same reason, the rings of the Pro and Hyp must point outward. These two amino acids help stabilize the triple helix—Hyp even more so than Pro; a lower concentration of them is required in animals such as fish, whose body temperatures are lower than most warm-blooded animals. Lower proline and hydroxyproline contents are characteristic of cold-water, but not warm-water fish; the latter tend to have similar proline and hydroxyproline contents to mammals.[16] The lower proline and hydroxproline contents of cold-water fish and other poikilotherm animals leads to their collagen having a lower thermal stability than mammalian collagen.[16] This lower thermal stability means that gelatin derived from fish collagen is not suitable for many food and industrial applications.

The tropocollagen subunits spontaneously self-assemble, with regularly staggered ends, into even larger arrays in the extracellular spaces of tissues.[22][23] Additional assembly of fibrils is guided by fibroblasts, which deposit fully formed fibrils from fibripositors.[2] In the fibrillar collagens, the molecules are staggered from each other by about 67 nm (a unit that is referred to as ‘D’ and changes depending upon the hydration state of the aggregate). Each D-period contains four plus a fraction collagen molecules, because 300 nm divided by 67 nm does not give an integer (the length of the collagen molecule divided by the stagger distance D). Therefore, in each D-period repeat of the microfibril, there is a part containing five molecules in cross-section, called the “overlap”, and a part containing only four molecules, called the “gap”.[24] The triple-helices are also arranged in a hexagonal or quasihexagonal array in cross-section, in both the gap and overlap regions.[24][25]

There is some covalent crosslinking within the triple helices, and a variable amount of covalent crosslinking between tropocollagen helices forming well organized aggregates (such as fibrils).[26] Larger fibrillar bundles are formed with the aid of several different classes of proteins (including different collagen types), glycoproteins and proteoglycans to form the different types of mature tissues from alternate combinations of the same key players.[23] Collagen’s insolubility was a barrier to the study of monomeric collagen until it was found that tropocollagen from young animals can be extracted because it is not yet fully crosslinked. However, advances in microscopy techniques (i.e. electron microscopy (EM) and atomic force microscopy (AFM)) and X-ray diffraction have enabled researchers to obtain increasingly detailed images of collagen structure in situ. These later advances are particularly important to better understanding the way in which collagen structure affects cell–cell and cell–matrix communication, and how tissues are constructed in growth and repair, and changed in development and disease.[27][28] For example, using AFM–based nanoindentation it has been shown that a single collagen fibril is a heterogeneous material along its axial direction with significantly different mechanical properties in its gap and overlap regions, correlating with its different molecular organizations in these two regions.[29]

Collagen fibrils/aggregates are arranged in different combinations and concentrations in various tissues to provide varying tissue properties. In bone, entire collagen triple helices lie in a parallel, staggered array. 40 nm gaps between the ends of the tropocollagen subunits (approximately equal to the gap region) probably serve as nucleation sites for the deposition of long, hard, fine crystals of the mineral component, which is (approximately) Ca10(OH)2(PO4)6.[30] Type I collagen gives bone its tensile strength.

Associated disorders

Collagen-related diseases most commonly arise from genetic defects or nutritional deficiencies that affect the biosynthesis, assembly, postranslational modification, secretion, or other processes involved in normal collagen production.

Genetic Defects of Collagen Genes
Type Notes Gene(s) Disorders
I This is the most abundant collagen of the human body. It is present in scar tissue, the end product when tissue heals by repair. It is found in tendons, skin, artery walls, cornea, the endomysiumsurrounding muscle fibers, fibrocartilage, and the organic part of bones and teeth. COL1A1, COL1A2 Osteogenesis imperfecta, Ehlers–Danlos syndrome, Infantile cortical hyperostosis a.k.a. Caffey’s disease
II Hyaline cartilage, makes up 50% of all cartilage protein. Vitreous humour of the eye. COL2A1 Collagenopathy, types II and XI
III This is the collagen of granulation tissue, and is produced quickly by young fibroblasts before the tougher type I collagen is synthesized. Reticular fiber. Also found in artery walls, skin, intestines and the uterus COL3A1 Ehlers–Danlos syndrome, Dupuytren’s contracture
IV Basal lamina; eye lens. Also serves as part of the filtration system in capillaries and the glomeruli ofnephron in the kidney. COL4A1, COL4A2,COL4A3, COL4A4,COL4A5, COL4A6 Alport syndrome, Goodpasture’s syndrome
V Most interstitial tissue, assoc. with type I, associated with placenta COL5A1, COL5A2,COL5A3 Ehlers–Danlos syndrome (Classical)
VI Most interstitial tissue, assoc. with type I COL6A1, COL6A2,COL6A3, COL6A5 Ulrich myopathy, Bethlem myopathy,Atopic dermatitis[31]
VII Forms anchoring fibrils in dermoepidermal junctions COL7A1 Epidermolysis bullosa dystrophica
VIII Some endothelial cells COL8A1, COL8A2 Posterior polymorphous corneal dystrophy 2
IX FACIT collagen, cartilage, assoc. with type II and XI fibrils COL9A1, COL9A2,COL9A3 EDM2 and EDM3
X Hypertrophic and mineralizing cartilage COL10A1 Schmid metaphyseal dysplasia
XI Cartilage COL11A1, COL11A2 Collagenopathy, types II and XI
XII FACIT collagen, interacts with type I containing fibrils, decorin and glycosaminoglycans COL12A1
XIII Transmembrane collagen, interacts with integrin a1b1, fibronectin and components of basement membranes like nidogen and perlecan. COL13A1
XIV FACIT collagen, also known as undulin COL14A1
XV COL15A1
XVI COL16A1
XVII Transmembrane collagen, also known as BP180, a 180 kDa protein COL17A1 Bullous pemphigoid and certain forms of junctional epidermolysis bullosa
XVIII Source of endostatin COL18A1
XIX FACIT collagen COL19A1
XX COL20A1
XXI FACIT collagen COL21A1
XXII COL22A1
XXIII MACIT collagen COL23A1
XXIV COL24A1
XXV COL25A1
XXVI EMID2
XXVII COL27A1
XXVIII COL28A1

In addition to the above-mentioned disorders, excessive deposition of collagen occurs in scleroderma.

Diseases

One thousand mutations have been identified in twelve out of more than twenty types of collagen. These mutations can lead to various diseases at the tissue level.[32]

Osteogenesis imperfecta – Caused by a mutation in type 1 collagen, dominant autosomal disorder, results in weak bones and irregular connective tissue, some cases can be mild while others can be lethal, mild cases have lowered levels of collagen type 1 while severe cases have structural defects in collagen.[33]

Chondrodysplasias – Skeletal disorder believed to be caused by a mutation in type 2 collagen, further research is being conducted to confirm this.[34]

Ehlers-Danlos Syndrome – Six different types of this disorder, which lead to deformities in connective tissue. Some types can be lethal, leading to the rupture of arteries. Each syndrome is caused by a different mutation, for example type four of this disorder is caused by a mutation in collagen type 3.[35]

Alport syndrome – Can be passed on genetically, usually as X-linked dominant, but also as both an autosomal dominant and autosomal recessive disorder, sufferers have problems with their kidneys and eyes, loss of hearing can also develop in during the childhood or adolescent years.[36]

Osteoporosis – Not inherited genetically, brought on with age, associated with reduced levels of collagen in the skin and bones, growth hormone injections are being researched as a possible treatment to counteract any loss of collagen.[37]

Knobloch syndrome – Caused by a mutation in the COL18A1 gene that codes for the production of collagen XVIII. Patients present with protrusion of the brain tissue and degeneration of the retina, an individual who has family members suffering from the disorder are at an increased risk of developing it themselves as there is a hereditary link.[32]

Characteristics

Collagen is one of the long, fibrous structural proteins whose functions are quite different from those of globular proteins, such as enzymes. Tough bundles of collagen calledcollagen fibers are a major component of the extracellular matrix that supports most tissues and gives cells structure from the outside, but collagen is also found inside certain cells. Collagen has great tensile strength, and is the main component of fascia, cartilage, ligaments, tendons, bone and skin.[38][39] Along with elastin and soft keratin, it is responsible for skin strength and elasticity, and its degradation leads to wrinkles that accompany aging.[10] It strengthens blood vessels and plays a role in tissue development. It is present in the cornea and lens of the eye in crystalline form. It may be one of the most abundant proteins in the fossil record, given that it appears to fossilize frequently, even in bones from the Mesozoic and Paleozoic.[40]

Uses

Collagen has a wide variety of applications, from food to medical. For instance, it is used in cosmetic surgery and burn surgery. It is widely used in the form of collagen casings for sausages, which are also used in the manufacture of musical strings.

If collagen is subject to sufficient denaturation, e.g. by heating, the three tropocollagen strands separate partially or completely into globular domains, containing a different secondary structure to the normal collagen polyproline II (PPII), e.g. random coils. This process describes the formation of gelatin, which is used in many foods, including flavoredgelatin desserts. Besides food, gelatin has been used in pharmaceutical, cosmetic, and photography industries.[41] From a nutritional point of view, collagen and gelatin are a poor-quality sole source of protein since they do not contain all the essential amino acids in the proportions that the human body requires—they are not ‘complete proteins‘ (as defined by food science, not that they are partially structured). Manufacturers of collagen-based dietary supplements usually containing hydrolyzed collagen claim that their products can improve skin and fingernail quality as well as joint health. However, mainstream scientific research has not shown strong evidence to support these claims.[42]Individuals with problems in these areas are more likely to be suffering from some other underlying condition (such as normal aging, dry skin, arthritis etc.) rather than just a protein deficiency.

From the Greek for glue, kolla, the word collagen means “glue producer” and refers to the early process of boiling the skin and sinews of horses and other animals to obtain glue. Collagen adhesive was used by Egyptians about 4,000 years ago, and Native Americans used it in bows about 1,500 years ago. The oldest glue in the world, carbon-dated as more than 8,000 years old, was found to be collagen—used as a protective lining on rope baskets and embroidered fabrics, and to hold utensils together; also in crisscross decorations on human skulls.[43] Collagen normally converts to gelatin, but survived due to dry conditions. Animal glues are thermoplastic, softening again upon reheating, and so they are still used in making musical instruments such as fine violins and guitars, which may have to be reopened for repairs—an application incompatible with tough, syntheticplastic adhesives, which are permanent. Animal sinews and skins, including leather, have been used to make useful articles for millennia.

Gelatin-resorcinolformaldehyde glue (and with formaldehyde replaced by less-toxic pentanedial and ethanedial) has been used to repair experimental incisions in rabbit lungs.[44]

History

The molecular and packing structures of collagen have eluded scientists over decades of research. The first evidence that it possesses a regular structure at the molecular level was presented in the mid-1930s.[45][46] Since that time, many prominent scholars, including Nobel laureates Crick, Pauling, Rich and Yonath, and others, including Brodsky,Berman, and Ramachandran, concentrated on the conformation of the collagen monomer. Several competing models, although correctly dealing with the conformation of each individual peptide chain, gave way to the triple-helical “Madras” model of Ramachandran, which provided an essentially correct model of the molecule’s quaternary structure[47][48][49] although this model still required some refinement.[50] [clarification needed] [51][52][53][54] The packing structure of collagen has not been defined to the same degree outside of the fibrillar collagen types, although it has been long known to be hexagonal or quasi-hexagonal.[25][55][56] As with its monomeric structure, several conflicting models alleged that either the packing arrangement of collagen molecules is ‘sheet-like’ or microfibrillar.[50][57][58] The microfibrillar structure of collagen fibrils in tendon, cornea and cartilage has been directly imaged by electron microscopy.[59][60][61] The microfibrillar structure of tail tendon, as described by Fraser, Miller, and Wess (amongst others), was modeled as being closest to the observed structure,[50] although it oversimplified the topological progression of neighboring collagen molecules, and hence did not predict the correct conformation of the discontinuous D-periodic pentameric arrangement termed simply: the microfibril.[24][62] Various cross linking agents like L-Dopaquinone, embeline, potassium embelate and 5-O-methyl embelin could be developed as potential cross-linking/stabilization agents of collagen preparation and its application as wound dressing sheet in clinical applications is enhanced.[63]

See also

References

  1. Jump up^ Di Lullo, Gloria A.; Sweeney, Shawn M.; Körkkö, Jarmo; Ala-Kokko, Leena & San Antonio, James D. (2002). “Mapping the Ligand-binding Sites and Disease-associated Mutations on the Most Abundant Protein in the Human, Type I Collagen”. J. Biol. Chem.277 (6): 4223–4231. doi:10.1074/jbc.M110709200. PMID 11704682.
  2. ^ Jump up to:a b c Sherman, Vincent R. (2015). “The materials science of collagen”. Journal of the Mechanical Behavior of Biomedical Materials 52: 22–50.doi:10.1016/j.jmbbm.2015.05.023.
  3. Jump up^ Britannica Concise Encyclopedia 2007
  4. Jump up^ Sikorski, Zdzisław E. (2001). Chemical and Functional Properties of Food Proteins. Boca Raton: CRC Press. p. 242. ISBN 1-56676-960-4.
  5. Jump up^ Bogue, Robert H. (1923). “Conditions Affecting the Hydrolysis of Collagen to Gelatin”.Industrial and Engineering Chemistry 15 (11): 1154–1159. doi:10.1021/ie50167a018.
  6. Jump up^ O.E.D. 2nd Edition 2005
  7. Jump up^ Müller, Werner E. G. (2003). “The Origin of Metazoan Complexity: Porifera as Integrated Animals”. Integrative and Comparative Biology 43 (1): 3–10. doi:10.1093/icb/43.1.3.
  8. Jump up^ Sabiston textbook of surgery board review, 7th edition. Chapter 5 wound healing, question 14
  9. Jump up^ Schauss, A., Stenehjem, J., Park, J., Endres, J., and Clewell, A. (2012). “Effect of the novel low molecular weight hydrolyzed chicken sternal cartilage extract, BioCell Collagen, on improving osteoarthritis-related symptoms: A randomized, double-blind, placebo-controlled trial”. Journal of Agricultural and Food Chemistry 60 (16): 4096–101.doi:10.1021/jf205295u. PMID 22486722.
  10. ^ Jump up to:a b Dermal Fillers | The Ageing Skin. Pharmaxchange.info. Retrieved on 2013-04-21.
  11. Jump up^ Cunniffe, G; F O’Brien (2011). “Collagen scaffolds for orthopedic regenerative medicine”.The Journal of the Minerals, Metals and Materials Society 63 (4): 66–73.Bibcode:2011JOM….63d..66C. doi:10.1007/s11837-011-0061-y.
  12. Jump up^ Oliveira, S; R Ringshia; R Legeros; E Clark; L Terracio; C Teixeira M Yost (2009). “An improved collagen scaffold for skeletal regeneration”. Journal of Biomedical Materials 94(2): 371–379. doi:10.1002/jbm.a.32694. PMC 2891373. PMID 20186736.
  13. Jump up^ Blow, Nathan (2009). “Cell culture: building a better matrix”. Nature Methods 6 (8): 619–622. doi:10.1038/nmeth0809-619.
  14. Jump up^ Birbrair, Alexander; Zhang, Tan; Files, Daniel C.; Mannava, Sandeep; Smith, Thomas; Wang, Zhong-Min; Messi, Maria L.; Mintz, Akiva; Delbono, Osvaldo (2014-11-06). “Type-1 pericytes accumulate after tissue injury and produce collagen in an organ-dependent manner”. Stem Cell Research & Therapy 5 (6): 122. doi:10.1186/scrt512. ISSN 1757-6512. PMC 4445991. PMID 25376879.
  15. Jump up^ Singh, O; SS Gupta; M Soni; S Moses; S Shukla; RK Mathur (2011). “Collagen dressing versus conventional dressings in burn and chronic wounds: a retrospective study”.Journal of Cutaneous and Aesthetic Surgery 4 (1): 12–16. doi:10.4103/0974-2077.79180. PMC 3081477. PMID 21572675.
  16. ^ Jump up to:a b c d e f Szpak, Paul (2011). “Fish bone chemistry and ultrastructure: implications for taphonomy and stable isotope analysis”. Journal of Archaeological Science 38 (12): 3358–3372. doi:10.1016/j.jas.2011.07.022.
  17. Jump up^ Diegelmann, Robert. “Collagen Metabolism”. Medscape.com. Medscape. Retrieved4 December 2014.
  18. Jump up^ Gorres, K. L.; Raines, R. T. (2010). “Prolyl 4-hydroxylase”. Crit. Rev. Biochem. Mol. Biol. 45 (2): 106–24. doi:10.3109/10409231003627991. PMC 2841224.PMID 20199358.
  19. Jump up^ Myllylä, R.; Majamaa, K.; Günzler, V.; Hanauske-Abel, H. M.; Kivirikko, K. I. (1984). “Ascorbate is consumed stoichiometrically in the uncoupled reactions catalyzed by propyl 4-hydroxylase and lysyl hydroxylase”. J. Biol. Chem. 259 (9): 5403–5. PMID 6325436.
  20. Jump up^ Houck, J. C.; Sharma, V. K.; Patel, Y. M.; Gladner, J. A. (1968). “Induction of Collagenolytic and Proteolytic Activities by AntiInflammatory Drugs in the Skin and Fibroblasts”. Biochemical Pharmacology 17 (10): 2081–2090. doi:10.1016/0006-2952(68)90182-2. PMID 4301453.
  21. Jump up^ Al-Hadithy, H.; Isenberg, DA; et al. (1982). “Neutrophil function in systemic lupus erythematosus and other collagen diseases”. Ann Rheum Dis 41 (1): 33–38.doi:10.1136/ard.41.1.33. PMC 1000860. PMID 7065727.
  22. Jump up^ Hulmes, D. J. (2002). “Building collagen molecules, fibrils, and suprafibrillar structures”. J Struct Biol 137 (1–2): 2–10. doi:10.1006/jsbi.2002.4450. PMID 12064927.
  23. ^ Jump up to:a b Hulmes, D. J. (1992). “The collagen superfamily—diverse structures and assemblies”.Essays Biochem 27: 49–67. PMID 1425603.
  24. ^ Jump up to:a b c Orgel, J. P.; Irving, TC; et al. (2006). “Microfibrillar structure of type I collagen in situ”. PNAS 103 (24): 9001–9005. Bibcode:2006PNAS..103.9001O.doi:10.1073/pnas.0502718103. PMC 1473175. PMID 16751282.
  25. ^ Jump up to:a b Hulmes, D. J. & Miller, A. (1979). “Quasi-hexagonal molecular packing in collagen fibrils”. Nature 282 (5741): 878–880. Bibcode:1979Natur.282..878H.doi:10.1038/282878a0. PMID 514368.
  26. Jump up^ Perumal, S.; Antipova, O. & Orgel, J. P. (2008). “Collagen fibril architecture, domain organization, and triple-helical conformation govern its proteolysis”. PNAS 105 (8): 2824–2829. Bibcode:2008PNAS..105.2824P. doi:10.1073/pnas.0710588105.PMC 2268544. PMID 18287018.
  27. Jump up^ Sweeney, S. M.; Orgel, JP; et al. (2008). “Candidate Cell and Matrix Interaction Domains on the Collagen Fibril, the Predominant Protein of Vertebrates”. J Biol Chem 283 (30): 21187–21197. doi:10.1074/jbc.M709319200. PMC 2475701. PMID 18487200.
  28. Jump up^ Twardowski, T.; Fertala, A.; et al. (2007). “Type I collagen and collagen mimetics as angiogenesis promoting superpolymers”. Curr Pharm Des 13 (35): 3608–3621.doi:10.2174/138161207782794176.
  29. Jump up^ Minary-Jolandan, M; Yu, MF (2009). “Nanomechanical heterogeneity in the gap and overlap regions of type I collagen fibrils with implications for bone heterogeneity”.Biomacromolecules 10 (9): 2565–70. doi:10.1021/bm900519v. PMID 19694448.
  30. Jump up^ Ross, M. H. and Pawlina, W. (2011) Histology, 6th ed., Lippincott Williams & Wilkins, p. 218.
  31. Jump up^ Söderhäll, C.; Marenholz, I.; Kerscher, T.; Rüschendorf, F; Rüschendorf, F.; Esparza-Gordillo, J.; Mayr, G; et al. (2007). “Variants in a Novel Epidermal Collagen Gene (COL29A1) Are Associated with Atopic Dermatitis”. PLoS Biology 5 (9): e242.doi:10.1371/journal.pbio.0050242. PMC 1971127. PMID 17850181.
  32. ^ Jump up to:a b Mahajan, VB, Olney, AH, Garrett, P, Chary, A, Dragan, E, Lerner, G, Murray, J & Bassuk, AG; Olney; Garrett; Chary; Dragan; Lerner; Murray; Bassuk (2010). “Collagen XVIII mutation in Knobloch syndrome with acute lymphoblastic leukemia”. American journal of medical genetics. Part A 152A (11): 2875–9. doi:10.1002/ajmg.a.33621.PMC 2965270. PMID 20799329.
  33. Jump up^ Gajko-Galicka, A (2002). “Mutations in type I collagen genes resulting in osteogenesis imperfecta in humans” (PDF). Acta biochimica Polonica 49 (2): 433–41.PMID 12362985.
  34. Jump up^ Horton, WA, Campbell, D, Machado, MA & Chou, J; Campbell; Machado; Chou (1989). “Type II collagen screening in the human chondrodysplasias”. American Journal of Medical Genetics 34 (4): 579–83. doi:10.1002/ajmg.1320340425. PMID 2624272.
  35. Jump up^ Hamel, BCJ; Pals, G.; Engels, CHAM; Akker, E.; Boers, GHJ; van Dongen, PWJ; Steijlen, PM (28 June 2008). “Ehlers-Danlos syndrome and type III collagen abnormalities: a variable clinical spectrum”. Clinical Genetics 53 (6): 440–446. doi:10.1111/j.1399-0004.1998.tb02592.x. PMID 9712532.
  36. Jump up^ Kashtan, CE (1993) “Collagen IV-Related Nephropathies (Alport Syndrome and Thin Basement Membrane Nephropathy)”, in RA Pagon, TD Bird, CR Dolan, K Stephens & MP Adam (eds), GeneReviews, University of Washington, Seattle, Seattle WA PMID 20301386.
  37. Jump up^ Shuster, S (2005). “Osteoporosis, a unitary hypothesis of collagen loss in skin and bone”.Medical Hypotheses 65 (3): 426–32. doi:10.1016/j.mehy.2005.04.027.PMID 15951132.
  38. Jump up^ Fratzl, P. (2008). Collagen: Structure and Mechanics. New York: Springer. ISBN 0-387-73905-X.
  39. Jump up^ Buehler, M. J. (2006). “Nature designs tough collagen: Explaining the nanostructure of collagen fibrils”. PNAS 103 (33): 12285–12290. Bibcode:2006PNAS..10312285B.doi:10.1073/pnas.0603216103. PMC 1567872. PMID 16895989.
  40. Jump up^ Zylberberg, L.; Laurin, M. (2011). “Analysis of fossil bone organic matrix by transmission electron microscopy”. Comptes rendus Palevol 11 (5–6): 357–366.doi:10.1016/j.crpv.2011.04.004.
  41. Jump up^ “Gelatin’s Advantages: Health, Nutrition and Safety”. gmap-gelatin.com. Archived fromthe original on May 5, 2006.
  42. Jump up^ European Food Safety Authority – EFSA Panel on Dietetic Products, Nutrition and Allergies. Scientific Opinion on the substantiation of a health claim related to collagen hydrolysate and maintenance of joints pursuant to Article 13(5) of Regulation (EC) No 1924/20061. EFSA Journal 2011;9(7):2291.
  43. Jump up^ Walker, Amélie A. (May 21, 1998). “Oldest Glue Discovered”. Archaeology.
  44. Jump up^ Ennker, I. C.; Ennker, JüRgen; et al. (1994). “Formaldehyde-free collagen glue in experimental lung gluing”. Ann Thorac Surg. 57 (6): 1622–1627. doi:10.1016/0003-4975(94)90136-8. PMID 8010812.
  45. Jump up^ Wyckoff, R.; Corey, R. & Biscoe, J. (1935). “X-ray reflections of long spacing from tendon”. Science 82 (2121): 175–176. Bibcode:1935Sci….82..175W.doi:10.1126/science.82.2121.175. PMID 17810172.
  46. Jump up^ Clark, G.; Parker, E.; Schaad, J. & Warren, W. J. (1935). “New measurements of previously unknown large interplanar spacings in natural materials”. J. Amer. Chem. Soc 57(8): 1509. doi:10.1021/ja01311a504.
  47. Jump up^ Balasubramanian, D . (October 2001). “GNR — A Tribute”. Resonance (Indian Academy of Sciences) 6 (10).
  48. Jump up^ Leonidas, Demetres D.; Chavali, GB; et al. (2001). “Binding of Phosphate and pyrophosphate ions at the active site of human angiogenin as revealed by X-ray crystallography”. Protein Science 10 (8): 1669–1676. doi:10.1110/ps.13601.PMC 2374093. PMID 11468363.
  49. Jump up^ Subramanian, Easwara (2001). “Obituary: G.N. Ramachandran”. Nature Structural & Molecular Biology 8 (6): 489–491. doi:10.1038/88544. PMID 11373614.
  50. ^ Jump up to:a b c Saad, Mohamed (Oct 1994). Low resolution structure and packing investigations of collagen crystalline domains in tendon using Synchrotron Radiation X-rays, Structure factors determination, evaluation of Isomorphous Replacement methods and other modeling. PhD Thesis, Université Joseph Fourier Grenoble I. pp. 1–221.doi:10.13140/2.1.4776.7844.
  51. Jump up^ Fraser, R. D.; MacRae, T. P. & Suzuki, E. (1979). “Chain conformation in the collagen molecule”. J Mol Biol 129 (3): 463–481. doi:10.1016/0022-2836(79)90507-2.PMID 458854.
  52. Jump up^ Okuyama, K.; Okuyama, K; et al. (1981). “Crystal and molecular structure of a collagen-like polypeptide (Pro-Pro-Gly)10“. J Mol Biol 152 (2): 427–443. doi:10.1016/0022-2836(81)90252-7. PMID 7328660.
  53. Jump up^ Traub, W.; Yonath, A. & Segal, D. M. (1969). “On the molecular structure of collagen”.Nature 221 (5184): 914–917. Bibcode:1969Natur.221..914T. doi:10.1038/221914a0.
  54. Jump up^ Bella, J.; Eaton, M.; Brodsky, B.; Berman, H. M. (1994). “Crystal and molecular structure of a collagen-like peptide at 1.9 A resolution”. Science 266 (5182): 75–81.Bibcode:1994Sci…266…75B. doi:10.1126/science.7695699. PMID 7695699.
  55. Jump up^ Jesior, J. C.; Miller, A. & Berthet-Colominas, C. (1980). “Crystalline three-dimensional packing is general characteristic of type I collagen fibrils”. FEBS Lett 113 (2): 238–240.doi:10.1016/0014-5793(80)80600-4. PMID 7389896.
  56. Jump up^ Fraser, R. D. B. & MacRae, T. P. (1981). “Unit cell and molecular connectivity in tendon collagen”. Int. J. Biol. Macromol. 3 (3): 193–200. doi:10.1016/0141-8130(81)90063-5.
  57. Jump up^ Fraser, R. D.; MacRae, T. P.; Miller, A. (1987). “Molecular packing in type I collagen fibrils”. J Mol Biol 193 (1): 115–125. doi:10.1016/0022-2836(87)90631-0.PMID 3586015.
  58. Jump up^ Wess, T. J.; Hammersley, AP; et al. (1998). “Molecular packing of type I collagen in tendon”. J Mol Biol 275 (2): 255–267. doi:10.1006/jmbi.1997.1449. PMID 9466908.
  59. Jump up^ Raspanti, M.; Ottani, V.; Ruggeri, A. (1990). “Subfibrillar architecture and functional properties of collagen: a comparative study in rat tendons”. J Anat. 172: 157–164.PMC 1257211. PMID 2272900.
  60. Jump up^ Holmes, D. F.; Gilpin, C. J.; Baldock, C.; Ziese, U.; Koster, A. J.; Kadler, K. E. (2001).“Corneal collagen fibril structure in three dimensions: Structural insights into fibril assembly, mechanical properties, and tissue organization”. PNAS 98 (13): 7307–7312.Bibcode:2001PNAS…98.7307H. doi:10.1073/pnas.111150598. PMC 34664.PMID 11390960.
  61. Jump up^ Holmes, D. F.; Kadler, KE (2006). “The 10+4 microfibril structure of thin cartilage fibrils”. PNAS 103 (46): 17249–17254. Bibcode:2006PNAS..10317249H.doi:10.1073/pnas.0608417103. PMC 1859918. PMID 17088555.
  62. Jump up^ Okuyama, K; Bächinger, HP; Mizuno, K; Boudko, SP; Engel, J; Berisio, R; Vitagliano, L (2009). “Comment on Microfibrillar structure of type I collagen in situ by Orgel et al. (2006), Proc. Natl Acad. Sci. USA, 103, 9001–9005”. Acta Crystallogr D Biol Crystallogr 65 (Pt9): 1009–10. doi:10.1107/S0907444909023051. PMID 19690380.
  63. Jump up^ Narayanaswamy, Radhakrishnan; Shanmugasamy, Sangeetha; Shanmugasamy, Sangeetha; Gopal, Ramesh; Mandal, Asit (2011). “Bioinformatics in crosslinking chemistry of collagen with selective crosslinkers”. BMC Research Notes 4: 399. doi:10.1186/1756-0500-4-399.

External links

12 types of collagen

////////

Share

Illegal Drugs in Dietary Supplements

 drugs  Comments Off on Illegal Drugs in Dietary Supplements
May 132016


thumbnail image: Illegal Drugs in Dietary Supplements

Illegal Drugs in Dietary Supplements

Forbidden stimulant oxilofrine found in various dietary supplements sold in the USA

Read more

http://www.chemistryviews.org/details/news/9278771/Illegal_Drugs_in_Dietary_Supplements.html





Oxilofrine (also known as methylsynephrine, hydroxyephrine, oxyephrine, and 4-HMP) is a stimulant drug[1] and is anamphetamine chemically related to ephedrine and to synephrine.

Oxilofrine is currently a WADA prohibited substance when used in competition.[2] It is an ingredient found in some dietary supplements.

Publicized cases

  • In 2009, Brazilian/American cyclist Flávia Oliveira was suspended for 2 years after taking a supplement known as “HyperDrive 3.0+” which contained methylsynephrine, a chemical equivalent of Oxilofrine, among other substances. [3] Her sentence was eventually reduced to 18 months after an appeal as there was enough evidence that she had unknowingly consumed said substance as the old label did not list methylsynephrine.[4]
  • On July 14, 2013, Jamaican runners Asafa Powell and Sherone Simpson tested positive for Oxilofrine prior to the 2013 World Athletics Championships. [5] Powell, however, maintained that he did not take any banned supplements knowingly or willfully.[6]Powell voluntarily withdrew as a result of the test. On 10 April 2014, both athletes received an 18-month suspension from competing, which was set to expire in December that year.[7] However, after appealing to the Court of Arbitration for Sport (CAS), both athletes’ suspensions were lifted on 14 July 2014.[8]
  • On July 16, 2015, Boston Red Sox pitching prospect Michael Kopech was suspended without pay for 50 games after testing positive for Oxilofrine, which is a banned substance under the Minor League Drug Prevention and Treatment Program. Kopech denied knowingly taking the substance.[9]









References

  1.  Fourcroy, Jean L. (2008). Pharmacology, doping and sports: a scientific guide for athletes, coaches, physicians, scientists and administrators. Taylor & Francis. ISBN 978-0-415-42845-3.
  2.  http://list.wada-ama.org/prohibited-in-competition/prohibited-substances/
  3.  Charles Pelkey (2010-04-13). “Oliveira suspended for two years”. Velonews.
  4.  Charles Pelkey (2011-02-24). “Court of Arbitration for Sport reduces Flavia Oliveira suspension”. Velonews.
  5.  Reuters. “Jamaicans Powell, Simpson test positive – SuperSport – Athletics”. SuperSport. Retrieved 2013-07-15.
  6.  “Jamaican Sprinter Asafa Powell slapped 18-month ban for doping”. IANS. news.biharprabha.com. Retrieved 10 April 2014.
  7.  “Asafa Powell banned for 18 months for doping”. BBC Sport. 10 April 2014. Archived from the original on 9 May 2014.
  8.  Drayton, John (14 July 2014). “Asafa Powell and Sherone Simpson given green light to return to action after sprinters have doping bans reduced to six months”. Mail Online. Retrieved14 July 2014.
  9.  Danny Wild (16 July 2015). “Red Sox No. 10 prospect Kopech suspended”. MiLB.com. Retrieved 8 March 2016
Oxilofrine
Oxilofrin Structural Formulae V.1.svg
Systematic (IUPAC) name
(1S*,2R*)-(±)-4-(1-Hydroxy-2-methylamino-propyl)phenol
Legal status
Legal status
  • Uncontrolled
Identifiers
CAS Number 365-26-4
ATC code none
PubChem CID 9701
ChemSpider 9320 Yes
UNII F49638UBDR Yes
KEGG D08314 Yes
ChEMBL CHEMBL30400 Yes
Chemical data
Formula C10H15NO2
Molar mass 181.23 g/mol

////Illegal Drugs, Dietary Supplements, Forbidden stimulant , oxilofrine, dietary supplements ,  USA, Oxilofrine

Share

Optimization of thermosensitive chitosan hydrogels for the sustained delivery of venlafaxine hydrochloride

 drugs  Comments Off on Optimization of thermosensitive chitosan hydrogels for the sustained delivery of venlafaxine hydrochloride
May 032016









Optimization of thermosensitive chitosan hydrogels for the sustained delivery of venlafaxine hydrochloride

Original Research Article

Pages 482-490

Ying Peng, Jie Li, Jing Li, Yin Fei, Jiangnan Dong, Weisan Pan

International Journal of Pharmaceutics

Volume 441, Issues 1–2, Pages 1-834 (30 January 2013)

  • Delivery of venlafaxine hydrochloride with thermosensitive chitosan hydrogels system: diffusion controlled release and kinetic gelation mechanism is nucleation and growth.
  • Abstract

    Chitosan/glycerophosphate disodium (GP) thermosensitive hydrogels were prepared for the sustained delivery of venlafaxine hydrochloride (VH) and optimization of this formulation was mainly studied. Release mechanism was investigated by applying various mathematical models to the in vitro release profiles. Overall, drug release from the hydrogels showed best fit in first-order model and drug release mechanism was diffusion-controlled release. Optimization of VH chitosan/GP thermosensitive hydrogels was conducted by using a three-level three-factorial Box–Behnken experimental design to evaluate the effects of considered variables, the strength of the formulation, chitosan concentration and GP amount, on the selected responses: cumulative percentage drug release in 1 h, 24 h and the rate constant. It presented that higher strength and GP concentration resulted in higher initial release and rate constant, which supported the hypothesis that the kinetic gelation mechanism of this system was nucleation and growth. Drug release profiles illustrated that controlled drug delivery could be obtained over 24 h, which confirmed the validity of optimization. In vivo pharmacokinetic study was investigated and it demonstrated that compared with VH solution, chitosan/GP thermosensitive hydrogels had a better sustained delivery of VH.

///////Optimization, thermosensitive chitosan hydrogels, sustained delivery, venlafaxine hydrochloride

Share

Twelve Principles for Drug Optimization

 DRUG DESIGN, drugs  Comments Off on Twelve Principles for Drug Optimization
Jan 092016




Twelve Principles for Drug Optimization
1. Increasing Potency
In the analogue class of the histamine H2-receptor antagonists (cimetidine, nizatidine, ranitidine, roxatidine, and famotidine), an increasing potency of the drug analogues can be observed. Famotidine is the most potent member of this class.
2. Improving the Ratio of the Main Activity to Adverse Affects
The pioneer drug of the adrenergic β-blockers is propranolol, which blocked both β1– and β2-receptors. However, blocking β2-receptors in asthma is harmful. Several selective blockers were developed and used in cardiology, such as atenolol, metoprolol, etc.

3. Improving the Physicochemical Properties with the Help of Analogues
Benzylpenicillin (penicillin G) was a pioneer antibiotic molecule, which could be administered only by intramuscular injection because of its acid-sensitivity. Through analogues, stable molecules were obtained and they could be given orally (e.g., ampicillin).

4. Decreasing Resistance to Anti-Infective Drugs
Resistance to anti-infective drugs has become an increasing problem all over the world. The widespread use of penicillin G led to an alarming increase of penicillin-G resistant Staphylococcus aureus infections in 1960. A solution to the problem was the design of penicillinase-resistant penicillins. Several examples show that analogues can also overcome the resistance to antifungal and antiviral drugs.

5 .Decreasing Resistance to Anticancer Agents
Imatinib is the pioneer drug for the treatment of chronic myelogenous leukemia. However, a significant number of patients develop resistance to imatinib. New analogues, such as dasatinib and nilotinib, have been introduced recently and it is hoped that these analogues will be effective in imatinib-resistant cases.

6. Improving Oral Bioavailability
A good oral bioavailability is necessary in most cases because the oral application of a drug is preferred to an injection therapy. Enalaprilat is an angiotensin-converting enzyme inhibitor which is used in intravenous administration for the treatment of hypertensive emergencies. Its ester prodrug has an excellent oral bioavailability, but it requires hydrolysis by esterases. Analogue-

based drug research afforded the lysylproline analogue, lisinopril, which has an acceptable bioavailability and it does not require metabolic activation.

7. Long-Acting Drugs for Chronic Diseases
Quaternary antimuscarinics are important drugs for the treatment of chronic obstructive pulmonary disease. Ipratropium bromide is a very active bronchodilator that is used several times daily. Its analogue is tiotropium with a longer duration of action which enables a once-daily dosing.

8. Ultrashort-Acting Drugs in Emergency Cases
Esmolol is an adrenergic β1-selective blocker with a very short duration of action. It is used when β-blockade of very short duration is desired in emergency situations.

9. Decreasing Interindividual Pharmacokinetic Differences
Omeprazole is a pioneer proton pump inhibitor that shows interindividual variability. Analogue-based drug discovery afforded pantoprazole with a linear, highly predictable pharmacokinetic property.

10. Decreasing Systemic Activities
For intranasal and inhalation applications of corticosteroids in the treatment of asthma and rhinitis, it is important to decrease the systemic availability of these drugs to avoid their adverse effects. Analogue research afforded budenoside and fluticasone with a low oral bioavailability.

11. Decreasing Drug Interactions with the Help of Analogues
Cimetidine inhibits CYPs, an important class of drug-metabolizing enzymes. This interaction inhibits the metabolism of certain drugs, such as propranolol, warfarin, diazepam, thus producing effects equivalent to an overdose of these medicines. These effects are avoided by analogues such as ranitidine and famotidine.

12. Synergistic Interactions between Analogues
Analogue-based drug research starting from ritonavir, which is an HIV-1 protease inhibitor, afforded the more potent lopinavir. However, it has a low plasma half- life. A combination of ritonavir and lopinavir is very successful, because ritonavir inhibits the P-450-mediated metabiolism of lopinavir.



Standalone Drugs Can Be Starting
Points for Drug Optimizations

We analyzed the Top 100 most frequently used drugs and nine standalone drugs were identified, that is, pioneer drugs for which there are no effective analogues. These are the following drugs: acetaminophen, acetylsalicylic acid, aripiprazole, bupropion, ezetimibe, lamotrigine, metformin, topiramate, and valproate semisodium.

Acetaminophen is one of the oldest drugs, which even nowadays has a broad application as an analgesic and antipyretic agent. However, acute overdose can cause severe hepatic damage.

Acetylsalicylic acid (aspirin) is also one of the oldest drugs and, contrary to acetaminophen, its mechanism of action is partly known: it irreversibly inhibits the cyclooxygenase-1 enzyme. A more potent derivative with a better adverse effect profile would be advantageous.

Aripiprazole is a relatively new antipsychotic drug which acts as a dopamine partial agonist for the treatment of schizophrenia. A more effective drug is needed for the treatment of refractory patients, to improve treatment of negative symptoms and cognitive dysfunction.

Bupropion is a unique antidepressant drug. It is the first non-nicotine medication for the treatment of smoking cessation.
Ezetimibe is a relatively new cholesterol absorption inhibitor. Its mechanism of action was discovered only recently (2005). Analogue-based drug research is underway.

Lamotrigine, topiramate, and valproate are widely used anticonvulsant drugs, whose mechanism of action is not known. Several efforts have been made to find better analogues, so far without positive results.

Metformin is already an old standalone drug for the treatment of type 2 diabetes. It is used alone or in combination with new antidiabetic agents. Its mechanism of action is not known which makes it difficult to conduct an analogue-based drug research.



/////////

Share

Spray drying

 drugs, GENERIC, SYNTHESIS  Comments Off on Spray drying
Jun 042015


Laboratory-scale spray dryer.
A=Solution or suspension to be dried in, B=Atomization gas in, 1= Drying gas in, 2=Heating of drying gas, 3=Spraying of solution or suspension, 4=Drying chamber, 5=Part between drying chamber and cyclone, 6=Cyclone, 7=Drying gas is taken away, 8=Collection vessel of product, arrows mean that this is co-current lab-spraydryer

Spray drying is a method of producing a dry powder from a liquid or slurry by rapidly drying with a hot gas. This is the preferred method of drying of many thermally-sensitive materials such as foods and pharmaceuticals. A consistent particle size distribution is a reason for spray drying some industrial products such as catalysts. Air is the heated drying medium; however, if the liquid is a flammable solvent such as ethanol or the product is oxygen-sensitive then nitrogen is used.[1]

All spray dryers use some type of atomizer or spray nozzle to disperse the liquid or slurry into a controlled drop size spray. The most common of these are rotary disks and single-fluid high pressure swirl nozzles. Atomizer wheels are known to provide broader particle size distribution, but both methods allow for consistent distribution of particle size.[2] Alternatively, for some applications two-fluid or ultrasonic nozzles are used. Depending on the process needs, drop sizes from 10 to 500 µm can be achieved with the appropriate choices. The most common applications are in the 100 to 200 µm diameter range. The dry powder is often free-flowing.[3]

The most common spray dryers are called single effect as there is only one drying air on the top of the drying chamber (see n°4 on the scheme). In most cases the air is blown in co-current of the sprayed liquid. The powders obtained with such type of dryers are fine with a lot of dusts and a poor flowability. In order to reduce the dusts and increase the flowability of the powders, there is since over 20 years a new generation of spray dryers called multiple effect spray dryers. Instead of drying the liquid in one stage, the drying is done through two steps: one at the top (as per single effect) and one for an integrated static bed at the bottom of the chamber. The integration of this fluidized bed allows, by fluidizing the powder inside a humid atmosphere, to agglomerate the fine particles and to obtain granules having commonly a medium particle size within a range of 100 to 300 µm. Because of this large particle size, these powders are free-flowing.

The fine powders generated by the first stage drying can be recycled in continuous flow either at the top of the chamber (around the sprayed liquid) or at the bottom inside the integrated fluidized bed. The drying of the powder can be finalized on an external vibrating fluidized bed.

The hot drying gas can be passed as a co-current or counter-current flow to the atomiser direction. The co-current flow enables the particles to have a lower residence time within the system and the particle separator (typically a cyclone device) operates more efficiently. The counter-current flow method enables a greater residence time of the particles in the chamber and usually is paired with a fluidized bed system.

Alternatives to spray dryers are:[4]

  1. Freeze dryer: a more-expensive batch process for products that degrade in spray drying. Dry product is not free-flowing.
  2. Drum dryer: a less-expensive continuous process for low-value products; creates flakes instead of free-flowing powder.
  3. Pulse combustion dryer: A less-expensive continuous process that can handle higher viscosities and solids loading than a spray dryer, and that sometimes gives a freeze-dry quality powder that is free-flowing.

Spray dryer

Spray drying nozzles.

Schematic illustration of spray drying process.

A spray dryer takes a liquid stream and separates the solute or suspension as a solid and the solvent into a vapor. The solid is usually collected in a drum or cyclone. The liquid input stream is sprayed through a nozzle into a hot vapor stream and vaporised. Solids form as moisture quickly leaves the droplets. A nozzle is usually used to make the droplets as small as possible, maximising heat transfer and the rate of water vaporisation. Droplet sizes can range from 20 to 180 μm depending on the nozzle.[3] There are two main types of nozzles: high pressure single fluid nozzle (50 to 300 bars) and two-fluid nozzles: one fluid is the liquid to dry and the second is compressed gas (generally air at 1 to 7 bars).

Spray dryers can dry a product very quickly compared to other methods of drying. They also turn a solution, or slurry into a dried powder in a single step, which can be advantageous for profit maximization and process simplification.



The Spray Drying Process

The spray drying process is older than might commonly be imagined.  Earliest descriptions date from 1860 with the first patented design recorded in 1872. The basic idea of spray drying is the production of highly dispersed powders from a fluid feed by evaporating the solvent. This is achieved by mixing a heated gas with an atomized (sprayed) fluid of high surface-to-mass ratio droplets, ideally of equal size, within a vessel (drying chamber), causing the solvent to evaporate uniformly and quickly through direct contact.
Spray drying can be used in a wide range of applications where the production of a free-flowing powder is required. This method of dehydration has become the most successful one in the following areas:

  • Pharmaceuticals
  • Bone and tooth amalgams
  • Beverages
  • Flavours, colourings and plant extracts
  • Milk and egg products
  • Plastics, polymers and resins
  • Soaps and detergents
  • Textiles and many more

Almost all other methods of drying, including use of ovens, freeze dryers or rotary evaporators, produce a mass of material requiring further processing (e.g. grinding and filtering) therefore, producing particles of irregular size and shape. Spray drying on the other hand, offers a very flexible control over powder particle properties such as density, size, flow characteristics and moisture content.



Spray drying dia

Design and Control

The challenges facing both designers and users are to increase production, improve powder quality and reduce costs. This requires an understanding of the process and a robust control implementation.



Spray drying consists of the following phases:



  • Feed preparation: This can be a homogenous, pumpable and free from impurities solution, suspension or paste.
  • Atomization (transforming the feed into droplets): Most critical step in the process. The degree of atomization controls the drying rate and therefore the dryer size. The most commonly used atomization techniques are:

1. Pressure nozzle atomization: Spray created by forcing the fluid through an orifice. This is an energy efficient method which also offers the narrowest particle size distribution.
2. Two-fluid nozzle atomization: Spray created by mixing the feed with a compressed gas. Least energy efficient method. Useful for making extremely fine particles.
3. Centrifugal atomization: Spray created by passing the feed through or across a rotating disk. Most resistant to wear and can generally be run for longer periods of time.

  • Drying: A constant rate phase ensures moisture evaporates rapidly from the surface of the particle. This is followed by a falling rate period where the drying is controlled by diffusion of water to the surface of the particle.
  • Separation of powder from moist gas: To be carried out in an economical (e.g. recycling the drying medium) and pollutant-free manner. Fine particles are generally removed with cyclones, bag filters, precipitators or scrubbers.
  • Cooling and packaging.



A control system must therefore provide flexibility in the way in which accurate and repeatable control of the spray drying is achieved and will include the following features:



  • Precise loop control with setpoint profile programming
  • Recipe Management System for easy parameterisation
  • Sequential control for complex control strategies
  • Secure collection of on-line data from the system for analysis and evidence
  • Local operator display with clear graphics and controlled access to parameters

Micro-encapsulation

Spray drying often is used as an encapsulation technique by the food and other industries. A substance to be encapsulated (the load) and an amphipathic carrier (usually some sort of modified starch) are homogenized as a suspension in water (the slurry). The slurry is then fed into a spray drier, usually a tower heated to temperatures well over the boiling point of water.

As the slurry enters the tower, it is atomized. Partly because of the high surface tension of water and partly because of thehydrophobic/hydrophilic interactions between the amphipathic carrier, the water, and the load, the atomized slurry forms micelles. The small size of the drops (averaging 100 micrometers in diameter) results in a relatively large surface area which dries quickly. As the water dries, the carrier forms a hardened shell around the load.[5]

Load loss is usually a function of molecular weight. That is, lighter molecules tend to boil off in larger quantities at the processing temperatures. Loss is minimized industrially by spraying into taller towers. A larger volume of air has a lower average humidity as the process proceeds. By the osmosis principle, water will be encouraged by its difference in fugacities in the vapor and liquid phases to leave the micelles and enter the air. Therefore, the same percentage of water can be dried out of the particles at lower temperatures if larger towers are used. Alternatively, the slurry can be sprayed into a partial vacuum. Since the boiling point of a solvent is the temperature at which the vapor pressure of the solvent is equal to the ambient pressure, reducing pressure in the tower has the effect of lowering the boiling point of the solvent.

The application of the spray drying encapsulation technique is to prepare “dehydrated” powders of substances which do not have any water to dehydrate. For example, instant drink mixes are spray dries of the various chemicals which make up the beverage. The technique was once used to remove water from food products; for instance, in the preparation of dehydrated milk. Because the milk was not being encapsulated and because spray drying causes thermal degradation, milk dehydration and similar processes have been replaced by other dehydration techniques. Skim milk powders are still widely produced using spray drying technology around the world, typically at high solids concentration for maximum drying efficiency. Thermal degradation of products can be overcome by using lower operating temperatures and larger chamber sizes for increased residence times.[6]

Recent research is now suggesting that the use of spray-drying techniques may be an alternative method for crystallization of amorphous powders during the drying process since the temperature effects on the amorphous powders may be significant depending on drying residence times.[7][8]

Spray drying applications

Food: milk powder, coffee, tea, eggs, cereal, spices, flavorings, starch and starch derivatives, vitamins, enzymes, stevia, colourings, etc.

Pharmaceutical: antibiotics, medical ingredients, additives

Industrial: paint pigments, ceramic materials, catalyst supports, microalgae

Nano spray dryer

The nano spray dryer offers new possibilities in the field of spray drying. It allows to produce particles in the range of 300 nm to 5 μm with a narrow size distribution. High yields are produced up to 90% and the minimal sample amount is 1 mL.



Pharmaceutical Spray drying is a very fast method of drying due to the very large surface area created by the atomization of the liquid feed. As a consequence, high heat transfer coefficients are generated and the fast stabilisation of the feed at moderate temperatures makes this method very attractive for heat sensitive materials.

Spray drying provides unprecedented particle control and allows previously unattainable delivery methods and molecular characteristics. These advantages allow exploration into employing previously unattainable delivery methods and molecular characteristics.

Five things you might not know about spray drying

  1. Spray drying is suitable for heat sensitive materials
    Spray drying is already used for the processing of heat sensitive materials (e.g. proteins, peptides and polymers with low Tg temperatures) on an industrial scale. Evaporation from the spray droplets starts immediately after contact with the hot process gas. Since the thermal energy is consumed by evaporation, the droplet temperature is kept at a level where no harm is caused to the product.
  2. Spray drying turns liquid into particles within seconds
    The large surface of the droplets provides near instantaneous evaporation, making it possible to produce particles with a crystalline or amorphous structure. The particle morphology is determined by the operating parameters and excipients added to the feed stock.
  3. Spray drying is relatively easy to replicate on a commercial scale
    GEA Niro has been producing industrial scale spray drying plants for well over half a century. Our process know-how, products and exceptional facilities put us in a unique position to advise and demonstrate how products and processes will behave on a large scale.
  4. Spray drying is a robust process
    Spray drying is a continuous process. Once the set points are established, all critical process parameters are kept constant throughout the batch. Information for the batch record can be monitored or logged, depending on the system selected.
  5. Spray drying can be effectively validated
    The precise control of all critical process parameters in spray drying provides a high degree of assurance that the process consistently produces a product that meets set specifi cations.

The spray drying process

Spray drying is a very fast method of drying due to the very large surface area created by the atomization of the liquid feed and high heat transfer coefficients generated. The short drying time, and consequently fast stabilisation of feed material at moderate temperatures, means spray drying is also suitable for heat-sensitive materials.

As a technique, spray drying consists of four basic stages:

  1. Atomization: A liquid feed stock is atomized into droplets by means of a nozzle or rotary atomizer. Nozzles use pressure or compressed gas to atomize the feed while rotary atomizers employ an atomizer wheel rotating at high speed.
  2. Drying: Hot process gas (air or nitrogen) is brought into contact with the atomized feed guided by a gas disperser, and evaporation begins. The balance between temperature, flow rate and droplet size controls the drying process.
  3. Particle formation: As the liquid rapidly evaporates from the droplet surface, a solid particle forms and falls to the bottom of the drying chamber.
  4. Recovery: The powder is recovered from the exhaust gas using a cyclone or a bag filter. The whole process generally takes no more than a few seconds.



References

  1.  A. S. Mujumdar (2007). Handbook of industrial drying. CRC Press. p. 710. ISBN 1-57444-668-1.
  2.  http://www.elantechnology.com/spray-drying/
  3.  Walter R. Niessen (2002). Combustion and incineration processes. CRC Press. p. 588. ISBN 0-8247-0629-3.
  4.  Onwulata p.66
  5.  Ajay Kumar (2009). Bioseparation Engineering. I. K. International. p. 179. ISBN 93-8002-608-0.
  6. Onwulata pp.389–430
  7.  Onwulata p.268
  8.  Chiou, D.; Langrish, T. A. G. (2007). “Crystallization of Amorphous Components in Spray-Dried Powders”. Drying Technology 25: 1427. doi:10.1080/07373930701536718.

Bibliography

Further reading

External links

TAKE A TOUR
TAKE A TOUR
Ahmednagar,  Maharashtra, India
////////////
Share
Follow

Get every new post on this blog delivered to your Inbox.

Join other followers:
